parameter：
|
model no. |
qy201 |
qy202 |
|
lifting capacity |
3.5t/4t |
4.5t |
|
max lifting height |
1820mm |
1820mm |
|
minimum height |
95mm |
95mm |
|
lifting time |
≤50s |
≤50s |
|
overall width |
3410mm |
3410mm |
|
overall height |
2860mm |
2860mm |
|
motor voltage |
380v/220v |
380v/220v |
|
motor power |
2.2kw |
2.2kw |
|
package size |
2960x465x735mm |
2960x465x735mm |
features：
1.the column with 8 bending
2. integral type carriage
3.manual two-side lock release system
4. dual balancing cable remote control for precise carriage movements
5. high load bearing chain,safe and reliable
6.every cylinder passes the pressure test
7.adopt quality power unit, more endurable,running safely and reliably
8.pass 115% dynamic overload test and 150% static overload test.
